LED RGB Tape Light 12V or 24V 12 in. Segment
RGB Color Changing LED Flexible Tape Light provides a dynamic, high-quality lighting solution to make your application stand out. It is commonly used for exhibit and display lighting, kitchen lighting, pool lights, home theater lighting, boat lights, or commercial lighting, and lighting design for museum lighting, architectural lighting, and restaurant lighting.
Each segment is 12 in. in length with pre-installed modular connectors at each end. You can utilize an LED strip light joiner and power feed for a solder-free installation. It is sold in 12 in. Segments and cuttable every 4" at its cutting mark.
* Required: Each run of LED RGB Tape Light requires RGB LED Power Feeds, 12V DC LED Driver, and Controllers. Sold separately.
Key Features
- Easy Installation
- Maintenance-free
- Solid-State Construction
- High shock and Vibration Resistance
- SMD 5050 RGB LEDs Chipsets
- No RF interference
- Up to 50,000 hours Lifespan
- CE Listed, RoHs
Applications
- Decorative Lighting for Tradeshows, Exhibition, Retail Displays
- Architectural lighting for corridors, canopies, archways, or windows
- Downlighting or Uplighting Applications
- Backlighting or edge-lighting for sign letters
- Under-cabinet, Under-Counter, or cove lighting
- Custom DIY projects
Specifications
Brightness | 500 Lumens/ft 1640 Lumens/meter |
---|---|
Power (Watts) | 3.9 watt/ft 12.8 watt/meter |
Input Voltage | 12V DC or 24V DC |
LED Colors | RGB |
IP Rating | IP20 |
Environment | Indoor Dry Location |
LED Beam Angle | 120° |
LED Density | 18 LEDs/ft |
LED Chip Size | SMD 5050 |
LED Spacing | 1.5 in / 38.1 mm |
Length | 12 in. Segment |
Width | 0.31 in / 8mm wide |
Height | 0.06 in / 1.52 mm thick |
Cutting Increment | 4 in / 101.6 mm at cut marking |
Adhesive Backing | 3M Adhesive |
Manufacturer | Elumalight |
Rating | UL, ETL, RoHS |
Avg. Lifetime | ± 30,000 - 50,000 hours |
Warranty | 3 years limited |
